CP770
Automatic Offset Printing Machine For Plastic Cup
Introduction
Mainly used in PP, HIPS, GPPS, EPS and other plastic cup printing, production of various yogurt cups, juice cups, jelly cups, ice cream cups, beverage cups printing.
call to us
If you have any questions?
| Number of color head | 4色(Colors) | 5、6、7色(Colors) |
| Max. production speed | 200只/分钟(Pieces/min) | 430只/分钟(Pieces/min) |
| Max. printing length | 680mm | 390/508mm |
| Max. Printing width | 150mm | 130mm |
| Max. diameter of container on the edge | 230mm | 140mm |
| Min. diameter of container on the edge | 70mm | 50mm |
| Max. height of container | 40-170mm | 40-170mm |
| Diameter of printing plate roller | 266mm | 177mm |
| Diameter of central roller | 522mm | 708mm |
| Printing sectors on central roller | 2 | 4 |
| Cup taper | 3-13° | 3-13° |
| Number of mandrels | 8 | 8 |
| Electrical installed power | 35kw | 35kw |
| UV power | 8kw(可调 Adjustable) | 8kw(可调 Adjustable) |
| Max. air consumption | 800升/分钟(L/min.) | 800升/分钟(L/min.) |
| Adjustable speed | 0到最大From 0 to max. | 0到最大From 0 to max. |
| Weight | 7000公斤kg approx. | 8000公斤kg approx. |
| Warranty period (CAM INDEX) | 5年(three years) | 5年(three years) |
